The S1 is a cast SG iron baffle type separator used for the removal of entrained liquids in steam, compressed air and gas systems. The fitting of insulation jackets will increase the performance of the separator.

This product fully complies with the requirements of the European Pressure Equipment Directive 97/23/EC.

This download includes all available size variations for the Spirax Sarco S1 SG Cast Iron Separator.

Object metadata

  • ModelS1 SG Iron Separator
  • CI/SFB Code(53)
  • Softwarerevit 2013
  • Uniclass60-45-40/130
  • Omniclass23.65.35.11
