The Altecnic Intaball lever ball valve with compression ends is the ideal isolation valve for use in copper pipe systems. Ideal for isolating individual outlets, ‘Y’ pattern strainers or control valves, should maintenance be required.

In larger systems they can provide isolation on heating, chilled and the primary side of HWS services on zones, branches or floors.

Design

The Intaball brass ball valves are lever operated through 90°, with bi-directional flow. The hard chrome plated ball provides increased wear resistance.

Compact design, with PTFE body seats for reliable isolation. The valves are designed for high flow rates with minimum pressure drops.

This download contains

1 Pipe Accessory Family with six types;AI-373R15 - 15mm CompressionAI-373R22 - 22mm CompressionAI-373R28 - 28mm CompressionAI-373R35 - 35mm CompressionAI-373R42 - 42mm CompressionAI-373R54 - 54mm Compression

Red Handle to indicate hot water

COBie and NBSCreate Parameters

Altecnic BIM Userguide
