The Imax Xtra EL range of twin condensation boilers is obtainable in five models with outputs from 715 to 1240kW appropriate for floor standing applications.

Features and advantages

• Simple management interface with large backlit display• Volt free contacts• 0-10V BMS operation standard• Robust metal silicon alloy heat exchanger• Suitable for single or multiple installations• Up to 109.8% part load efficiency• two Years components and labour guarantee• NOx <40mg/kWh• Natural Gas

Optional extras include:

• Flow and return headers 5" connection• Gas header 3" connection• Dual air inlet

This download includes all Imax Xtra EL versions available from Ideal Commercial Boilers from 320 - 1240 kW.

The Imax Xtra EL content contains user selectable clearance zones.
