The UNIMAT UT-L three-pass design has proven its worth for industrial heating systems. Our versatile steel boilers are CE certified and are designed and equipped in compliance with the European Pressure Equipment Directive

The UNIMAT UT-L steel boiler is ideal for hospitals, office buildings and residential blocks as well as other industrial heating system. Its high level of flexibility makes the UNIMAT UT-L ideally suitable for use as a reserve and peak load boiler within power stations and combined heat and power plants.

This download contains Revit components for the UNIMAT UT-L Steel Hot Water Boiler from outputs 650kW up to 19,200kW (33 types).

Components include user selctable features and guidance regarding burners, heat exchangers, manufacturer recommend clearance zones and more.

Rev 2 - version update / colour brand changesRead more
