Our proven UNIMAT three-pass design has been used for decades – with overwhelming success. The UT-M steel boiler is offered in various sizes and can also be used in a combined output multi-boiler system. It is CE certified and is designed and equipped in compliance with the European Pressure Equipment Directive.

The UT-M's exceptional performance is most evident in central heating systems for district and local community heating. However, the versatile hot water boiler is also used in a wide variety of commercial and industrial heating applications.

This download contains Revit components for the UNIMAT UT-M Hot Water Boiler from outputs 750kW up to 19,200kW (32 types).

Components include user selctable features and guidance regarding burners, heat exchangers, manufacturer recommend clearance zones and more.

Rev 2 - version update / brand colour changesRead more
